ANTENNA AMPLIFIER AWS-143M AMS
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
Frequency range: 87 MHz ... 694 MHz ; Number of inputs/outputs: 1 / 3 ; Gain : 15 / 20 dB ;
| Frequency range: | 87 MHz ... 694 MHz |
| Number of inputs/outputs: | 1 / 3 |
| Input/output impedance: | 75 Ω |
| Connectors type: | "F" |
| Gain : | 15 / 20 dB ± 2 dB |
| Gain adjustment: | 0 ... 10 dB ± 2 dB |
| S/N ratio: | ≤ 4 dB |
| Maximum output level: | 102 dBµV (2kTV) |
| IMA3 60dB: | 97 dBµV |
| IMA2 60dB: | 84 dBµV |
| Return loss: | ≥ 10 dB |
| Pre-amplifiers powering: |  |
| Main features: | |
| Operation temp: | -25 °C ... 55 °C |
| Power supply: | |
| Weight: | 0.1 kg |
| Dimensions: | 112 x 64 x 29 mm |
| Manufacturer / Brand: | AMS |
| Guarantee: | 2 years |
Brand:
AMS
