CONFIGURABLE CHANGE-OVER RELAYS MODULE PK2-12-PWT DELTA
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
Number of relay outputs: 2 ; Power supply: 10 ... 16 V DC ; Relay maximal load: max. 2 x 10 A, 30 V DC / 50 V AC ; Output: 2 x NO/NC ; Main features: LED indication, Splash-proof casing ;
| Number of relay outputs: | 2 |
| Power supply: | 10 ... 16 V DC |
| Current consumption: | max. 2 x 35 mA / 12 V DC |
| Relay maximal load: | max. 2 x 10 A, 30 V DC / 50 V AC |
| Relay switching voltage H: | > 4 V |
| Relay switching voltage L: | < 2.7 V |
| Output: | 2 x NO/NC |
| Main features: | |
| Operation temp: | -10 °C ... 40 °C |
| Weight: | 0.11 kg |
| Dimensions: | 120 x 90 x 36 mm |
| Manufacturer / Brand: | DELTA |
| Guarantee: | 3 years |
Brand:
Delta
