Автоматический выключатель дифференциального тока HNC-40/2/003 переменного тока, 30 мА, 40 А, EATON
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
Device type: Residual current circuit breaker, AC type ; Rated sensitivity: 30 mA ; Rated current: 40 A ; Number of poles: 2 ; Breaking capacity: 6000 A ; Connectors type: screw terminals ; Wire gauge: 1.5 mm² - 35 mm² or 2 x 16 mm² ; Housing: DIN, TS-35 rail mounting ;
| Device type: | Residual current circuit breaker, AC type |
| Rated sensitivity: | 30 mA |
| Rated current: | 40 A |
| Number of poles: | 2 |
| Breaking capacity: | 6000 A |
| Rated voltage: | 230 V / 50 Hz |
| Connectors type: | screw terminals |
| Wire gauge: | 1 x 1.5 mm² - 35 mm² or 2 x 16 mm² |
| Main features: | |
| Housing: | Plastic, DIN, TS-35 rail mounting |
| Width in 17.5 mm modules: | 2 |
| Weight: | 0.195 kg |
| Dimensions: | 35 x 80 x 76 mm |
| Manufacturer / Brand: | EATON |
| Guarantee: | 2 years |
Brand:
Eaton
