ANTENNA AMPLIFIER MX-062 FM / VHF / UHF 12V TERRA
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
Frequency range: FM : 88 MHz ... 108 MHz VHF : 174 MHz ... 230 MHz UHF : 470 MHz ... 862 MHz ; Gain : FM : 30 dB VHF : 30 dB UHF : 34 dB ;
| Frequency range: | |
| Gain : | |
| S/N ratio: | |
| Return loss: | > 10 dB |
| Number of inputs/outputs: | 3 / 1 |
| IMA3 60dB: | 105 dBµV |
| Amplifier shield: |  |
| Input/output impedance: | 75 Ω |
| Connectors type: | "F" |
| Housing: | die-cast housing mounted inside compact plastic enclosure |
| Mounting: | on a mast or a wall |
| Operation temp: | -20 °C ... 50 °C |
| Power supply: | 12 V DC / 80 mA |
| Weight: | 0.176 kg |
| Dimensions: | 107 x 89 x 43 mm |
| Manufacturer / Brand: | TERRA |
| Guarantee: | 2 years |
Brand:
Terra
