Power supply: 11 V ... 15 V DC ; Relay outputs: 8 x NO/NC ; Relay outputs changeover time in monostable mode: 0.5 s ... 4 hours ;
| Type: | Superheterodyne |
| Power supply: | 11 V ... 15 V DC |
| Current consumption: | max. 180 mA |
| Relay outputs: | 8 x NO/NC |
| Output: | 1 S(1A/60VDC), "Open Collector" providing pulses of short to ground |
| Relay outputs changeover time in monostable mode: | 0.5 s ... 4 hours |
| Relay change indication: | By two-color LED |
| Main features: | |
| Weight: | 0.1 kg |
| Dimensions: | 97 x 63 x 28 mm |
| Operation temp: | 0 °C ... 40 °C |
| Manufacturer / Brand: | ELMES |
| Guarantee: | 2 years |
