CEILING PIR DETECTOR SLIM-R-PIR-AC SATEL
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
Application: Indoor ; Sensor type: Passive Infra Red (PIR) ; Range: from a height 2.4 m area 56 m² from a height 3 m area 80 m² ;
| Application: | Indoor |
| Pyroelectric sensor: | Double |
| Sensor type: | Passive Infra Red (PIR) |
| Range: | from a height 2.4 m area 56 m² from a height 3 m area 80 m² |
| Sensitivity adjustment: | By potentiometer |
| Recommended installation height: | 2.4 m ... 3.5 m |
| Maximal outputs load: | 8 A / 250 V DC |
| Digital temperature compensation: |  |
| Target speed range: | 0.3 ... 3 m/s |
| Power supply: | 230 V AC / 50 Hz |
| Main features: | |
| Operation temp: | -10 °C ... 55 °C |
| Weight: | 0.14 kg |
| Dimensions: | Ø 130 x 42 mm |
| Manufacturer / Brand: | SATEL |
| Guarantee: | 5 years |
Brand:
Satel
