SWITCH POE DS-3E1552P-SI 48-PORT SFP Hikvision

€614.39

(Включая налог 21%)

Задать вопрос

КОД: DS-3E1552P-SI

Доступность: 1 шт.

Кол-во:

+ −

Минимальное количество для товара "SWITCH POE DS-3E1552P-SI 48-PORT SFP Hikvision" 1.

Описание
Особенности

LAN ports: 48 x RJ45 ( 48 x PoE (802.3af/at) ), 2 x RJ45 (Uplink), 2 x SFP (Uplink) ; Transmission speed: 10 / 100 / 1000 Mbps - 48 LAN & PoE ports, 10 / 100 / 1000 Mbps - 2 RJ45 (Uplink) ports, 1000 Mbps - 2 SFP (Uplink) ports ; Maximal total power: 470 W ;

LAN ports:	48 x RJ45 ( 48 x PoE (802.3af/at) ), 2 x RJ45 (Uplink), 2 x SFP (Uplink)
Management:
LED diodes:	Power, Link/Act, PoE, PoE Max
Transmission speed:	10 / 100 / 1000 Mbps - 48 LAN & PoE ports, 10 / 100 / 1000 Mbps - 2 RJ45 (Uplink) ports, 1000 Mbps - 2 SFP (Uplink) ports
Maximal output power:	30 W / port PoE
Maximal total power:	470 W
Switching capacity:	104 Gb/s
Forwarding rate:	77.38 Mpps
MAC addresses table:	16k
Default IP address:	192.168.1.64
Default admin user / password:	admin / -
Operation modes:	Long Range - 300 m, 10 Mbps - 1 ... 48 ports Port Isolation - 1 ... 48 ports Watchdog PoE - 1 ... 48 ports
Main features:	Switch is web managed Configuration and management from the iVMS-4200 application HPP - Hik-Partner Pro support - View topology and network status, Data Flow Control , Remote update of software, Remote configuration Port Isolation - 1 ... 48 ports are isolated from each other and separately work with the Uplink ports PoE Watchdog mode - monitoring of the ports that power PoE devices and automatic restart by cutting off the power supply when an unresponsive device is detected Static link aggregation - Link aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection Support 8 aggregation groups QoS : Queue scheduling: SP, WRR, SP+WRR Loop Protection - IEEE 802.1d, IEEE 802.1w, Spanning Tree STP/RSTP VLAN - IEEE 802.1Q standard support, up to 4094 VLAN groups and 1 ... 4094 VIDs Port/flow-based rate limiting Storm Control function SNMP The device supports 8-pin power supply : 1-2(-), 3-6(+), 4-5(+), 7-8(-) RESET button Can be mounted in a Rack 19" cabinet
Certificates:	CE, RoHS, WEEE
Protections:	Overvoltage 6 kV - PoE ports
Housing:	Metal
Color:	Graphite
Power supply:	100 ... 240 V AC
Power consumption:	max. 500 W
Operation temp:	0 °C ... 45 °C
Weight:	4.21 kg
Dimensions:	440 x 324 x 44 mm, RACK 19", 1U
Manufacturer / Brand:	Hikvision
SAP Code:	301802631
Guarantee:	3 years
