Frequency range: Wi-Fi 2.4 GHz, 5 GHz ; 5G NR NSA/SA Sub-6 GHz, 4G LTE, 3G WCDMA ; Antenna type: 4 x Omnidirectional antenna Wi-Fi - built-in, 4 x Omnidirectional antenna 5G/4G - built-in + 2 x SMA connector for connecting an external antenna ; Standards: IEEE 802.11ax/ac/n/b/g @ 2.4 GHz, IEEE 802.11 ax/ac/an/a @ 5 GHz ; Baud rates: Wi-Fi 6 : 574 Mbps + 2402 Mbps, 5G SA Sub-6 : max. 2.4 Gb/s (DL) / 900 Mbps (UL), 5G NSA Sub-6 : max. 3.4 Gb/s (DL) / 550 Mbps (UL), ; SIM socket: 1 x nano SIM, 1 x eSIM ;
| Frequency range: | |
| Antenna type: | |
| Standards: | IEEE 802.11ax/ac/n/b/g @ 2.4 GHz , IEEE 802.11 ax/ac/an/a @ 5 GHz |
| Baud rates: | |
| LAN ports: | 1 x 10/100/1000 Mbps - WAN / LAN 2 x 10/100/1000 Mbps - LAN |
| LED indicators: | Power, INTERNET, WiFi, 5G/4G |
| SIM socket: | 1 x nano SIM , 1 x eSIM |
| DHCP server: | ![]() |
| Protections: | Firewall, Protection against DoS attacks, Ping packets blocking from WAN, VPNs (Server/Client): WireGuard, OpenVPN, IPsec, Zerotier, PPTP, L2TP, IP addresses filtering, MAC addresses filtering, domain filtering |
| Management interface: | |
| Main features: | |
| Power supply: | 12 V DC / 2.5 A (power adapter included) |
| Operation temp: | 0 °C ... 45 °C |
| Permissible relative humidity: | 5 % ... 95 % (non-condensing) |
| Weight: | 0.66 kg |
| Dimensions: | Ø 116 x 202 mm |
| Manufacturer / Brand: | CUDY |
| Guarantee: | 2 years |
