POE POWER ADAPTER POE-48/NX-1G 24 W DELTA NETWORK
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
The POE-48/NX-1G is designed to powering devices using PoE technology; Baud rates: 10 / 100 / 1000 Mbps ; Input voltage: 100 V ... 240 V AC ; Output voltage: 48 V DC ; Output power: 24 W ;
| Baud rates: | 10 / 100 / 1000 Mbps |
| Standards: | IEEE 802.3at |
| Input voltage: | 100 V ... 240 V AC |
| Output voltage: | 48 V DC |
| Number of inputs: | 1 |
| Connector: | 2 x RJ-45 socket |
| LED indicators: | Power connection |
| Output power: | 24 W |
| Protections: | |
| Housing: | Plastic |
| Pin numbers for RJ-45 connector: | DATA : 1, 2 and 3, 6 Power supply : 4, 5 (+) and 7, 8 (-) |
| Operation temp. / Relative humidity: | 0 °C ... 40 °C / 5 % ... 90 % |
| Weight: | 0.187 kg |
| Dimensions: | 85 x 44 x 30 mm |
| Manufacturer / Brand: | DELTA NETWORK |
| Guarantee: | 2 years |
Brand:
Delta Network
