CONVERTER MODULE PZU-3509-W4 DC/DC
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
Type: Increasing the voltage, DC/DC ; Number of inputs: 2 - closed ; Number of outputs: 2 - closed ; Power voltage: 5 ... 32 V DC ; Output voltage: 5 ... 35 V DC ; Output current: 2 A (max) ; Power: 24 W (max) ;
| Type: | Increasing the voltage, DC/DC |
| Number of inputs: | 2 - closed |
| Number of outputs: | 2 - closed |
| Power voltage: | 5 ... 32 V DC |
| Output voltage: | 5 ... 35 V DC |
| Output voltage adjustment: | Multi-turn precision potentiometer adjustment (27 rotations) |
| Output current: | 2 A (max) |
| Power: | 24 W (max) |
| Minimal voltage difference between out and in: | 0 V |
| Protections: | |
| Main features: | LED indication - Input voltage, Output voltage |
| Application: | |
| Weight: | 0.09 kg |
| Dimensions: | 120 x 90 x 36 mm |
| Manufacturer / Brand: | DELTA |
| Guarantee: | 3 years |
Brand:
Delta
