BUFFERED SWITCHING POWER SUPPLY ADAPTER AUPS-70-120-F ATTE
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
Input voltage: 190 ... 260 V AC ; Output voltage: 10.2 ... 13.8 V DC (buffer operation) ; Max. output current (total): 6 A (continuous operation) ; Battery charging current: 1 A / 2 A ; Number of outputs: 1 ; Main features: Efficiency : 90 % ;
| Adapter type: | Transforming |
| Input voltage: | 190 ... 260 V AC / 50 Hz |
| Output voltage: | 10.2 ... 13.8 V DC (buffer operation) |
| Max. output current (total): | 6 A (continuous operation) |
| Battery charging current: | 1 A / 2 A - Jumper on JP1 |
| Power: | 72 W (continuous operation) |
| Number of outputs: | 1 |
| Main features: | |
| Protections: | |
| Adapter operation control: | |
| Place for battery: | 12 V / 7 ... 18 Ah |
| Max. battery dimensions: | 220 x 170 x 100 mm |
| Operation temp: | -25 ... 50 °C |
| Weight: | 2.3 kg |
| Dimensions: | 325 x 305 x 88 mm |
| Manufacturer / Brand: | ATTE |
| Guarantee: | 3 years |
Brand:
ATTE
