Lens: 2.3 mm ; View angle: 120 ° ; IR illuminator: 10 m ; Wireless transmission range: The range limited only by the availability of the Wi-Fi network ; Main features: Motion Detection Detection of people and vehicles Bidirectional communication Video PUSH personal messaging ;
| Application: | Wireless Door Chime - DS1AG, DMSS application |
| Sensor: | Progressive Scan CMOS - 4 Mpx |
| Resolution: | 2560 x 1440 px - 4 Mpx |
| Lens: | 2.3 mm |
| View angle: | 120 ° |
| IR illuminator: | 10 m |
| LED illuminator: | ![]() |
| Frequency band: | 2.4 GHz |
| Wireless transmission range: | The range limited only by the availability of the Wi-Fi network |
| Wi-Fi standard: | IEEE 802.11 b/g/n/ax |
| Network interface: | 2.4 GHz |
| Mobile phones support: | Android: DMSS free application iOS (iPhone): DMSS free application |
| Image compression method: | H.265, H.264 |
| Main features: | |
| Mount: | Surface-mounted |
| Power supply: | |
| Power consumption: | ≤ 5.3 W @ 5 V DC ≤ 6.8 W @ 10 ... 24 V DC / 14 ... 24 V AC |
| Housing: | Plastic |
| Color: | White |
| "Index of Protection": | IP65 |
| Operation temp: | -30 °C ... 60 °C |
| Weight: | 0.11 kg |
| Dimensions: | 135 x 45 x 24 mm |
| Manufacturer / Brand: | DAHUA |
| Guarantee: | 2 years |
