SET OF UTP / 2-WIRE CONVERTERS FOR LAN+POE TRANSMISSION ETH10-2WIRE-A-SET 2 PCS SET ATTE
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
Transmission speed: 10 Mbps ; Transmission range: 1000 m @ 2-wire ;
| Connectors: | |
| LAN ports: | 1 pcs RJ45 10 Mbps |
| Connectors description: | ETH10-2WIRE-A-TX : ("+/-": 1, 2 pins; "+/-": 3, 6 pins) or ("+/-": 4, 5 pins; "+/-": 7, 8 pins) ("-": pins 1, 2; "+": pins 3, 6; "+": pins 4, 5; "-": pins 7, 8) |
| Transmission speed: | 10 Mbps |
| Transmission range: | 1000 m @ 2-wire |
| LED indicators: | |
| Protections: | |
| Main features: | |
| Power supply: | ETH10-2WIRE-A-TX : |
| Power consumption: | 0.7 W (total) |
| Housing: | Plastic (PC) |
| "Index of Protection": | IP20 |
| Operation temp: | -25 °C ... 65 °C |
| Weight: | 0.03 kg (single element) |
| Dimensions: | 51 x 51 x 23 mm (single element) |
| Manufacturer / Brand: | ATTE |
| Guarantee: | 3 years |
Brand:
ATTE
