AHD, HD-CVI, HD-TVI, CVBS, IP DVR APTI-XB0801H-S35 8 CHANNELS
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
Audio inputs: 1 pcs CINCH, 8 - Audio support via coaxial cable ; Image compression method: H.265+ ; Image records resolutions: AHD / HD-TVI : 8M-N - 1920 x 2160 px, 5 Mpx - 2592 x 1944 px, HD-CVI : 8M-N - 1920 x 2160 px, 4 Mpx - 2560 x 1440 px, CVBS : 960H - 960 x 576 px, IP : max. 8.3 Mpx - 3840 x 2160 px ; Supported hard drives: 1 x 8 TB SATA ;
| Standard: | AHD, HD-CVI, HD-TVI, PAL, TCP/IP |
| Video inputs: | 8 pcs BNC - AHD / HD-CVI / HD-TVI / CVBS |
| Video outputs: | |
| Audio inputs: | |
| Audio outputs: | 1 pcs CINCH |
| Image compression method: | H.265+ / H.265 / H.264+ / H.264 |
| Image records resolutions: | 8M-N - 1920 x 2160 px, 5 Mpx - 2592 x 1944 px, 5M-N - 1296 x 1944 px, 4 Mpx - 2560 x 1440 px, 4M-N - 1280 x 1440 px, 3 Mpx - 2048 x 1536 px, 1080p - 1920 x 1080 px, 720p - 1280 x 720 px, 8M-N - 1920 x 2160 px, 4 Mpx - 2560 x 1440 px, 4M-N - 1280 x 1440 px, 1080p - 1920 x 1080 px, 720p - 1280 x 720 px, 960H - 960 x 576 px, max. 8.3 Mpx - 3840 x 2160 px |
| Recording speed adjustment: | 8.3 Mpx IP @ 1 ... 25 fps 8M-N @ 1 ... 8 fps 5 Mpx @ 1 ... 6 fps 5M-N @ 1 ... 10 fps 4 Mpx @ 1 ... 8 fps 4M-N @ 1 ... 15 fps 3 Mpx @ 1 ... 9 fps 1080p @ 1 ... 15 fps 720p @ 1 ... 25 fps 960H @ 1 ... 25 fps for each channel |
| Operation modes: | / IP + 8 x IP |
| Recording modes: | Manual, Sensor, Motion detection, Schedule |
| Supported hard drives: | 1 x 8 TB SATA |
| External storage devices backup: | Records backup at (.avi) format to USB (pendrive) |
| Searching and playback the records: | Records searching: timeline or file list. Playback: forward, backward, fast, slow. Records playback from max. 4 channels in the same time |
| Network functions: | |
| Mobile phones support: | Port no.: 6000 or access by a cloud (P2P) |
| Default IP address: | 192.168.1.88 |
| Default admin user / password: | admin / 12345 |
| Web browser access ports: | 80, 5000, 554 |
| PC client access ports: | 80, 5000, 554 |
| Mobile client access ports: | 80, 5000, 6000 |
| Alarm inputs / outputs: | 4 / 2 |
| PTZ control: | Pelco-D, Pelco-P |
| Motion Detection: | Split the screen into zones : 22 x 18 motion zones |
| USB: | 2 pcs USB 2.0 |
| Mouse support: |  |
| IR remote controller in the set: |  |
| Power supply: | 12 V DC / 2 A (power adapter included) |
| Color: | Black |
| Weight: | 0.77 kg |
| Dimensions: | 260 x 242 x 45 mm |
| Supported languages: | Polish, English, Bulgarian, Czech, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Romanian, Turkish, Hungarian, Italian |
| Country of origin: | China |
| Manufacturer / Brand: | APTI |
| Guarantee: | 2 years |
